AVTECH NVR Recorders
aantal IP-camera's |
max. resolutie camera's |
IPS |
H.265 |
PoE poorten |
PushVideo |
harddisks |
monitor aansluitingen |
EaZy |
||
AVH0401 | 4 | 1280x1024 | 120 | - | 4 | ja | 1 (tot 4TB) | HDMI | ja | |
DGH1104 | 4 | 3264x2448 | 120 | ja | 4 | - | 1 (tot 10TB) | HDMI+VGA | ja | |
DGH1108 | 8 + 1 | 3264x2448 | 270 | ja | - | - | 1 (tot 14TB) | HDMI+VGA | ja | |
AVH1109AX | 8 + 1 | 3264x2448 | 270 | ja | 8 | ja | 1 (tot 16TB) | HDMI+VGA | ja | |
AVH2117AX | 16 | 3860x2160 | 480 | ja | 16 | ja | 2 (tot 16TB) | HDMI + VGA | ja |


AVH0401
AVTECH 4CH HD Video Recorder Up to 120 IPS @ 1280x1024, 32 Mbps
De AVH0401 is een 4-kanaals NVR. De NVR is geschikt voor max. 4 IP-camera's met een resolutie tot 1280x1024 beeldpunten.De Full HD (1920x1080) video output op de HDMI aansluiting biedt het beste beeld op LCD en LED monitoren. De AVH0401 kan worden voorzien van één harde schijf tot 4 TB en biedt de mogelijk om externe disk arrays aan te sluiten voor maximale opslag mogelijkheden. KENMERKEN HD real-time recording biedt heldere beelden voor video recording en playback max. 120 IPS (images per seconde) @1280x1024, 32 Mbps 4 netwerkaansluitingen met PON (Power over Network) voor IP-camera's 1 Gigabit netwerkaansluiting voor netwerk/internet HD video output, beschikbaar via HDMI poort, biedt de beste beeldkwaliteit op LCD monitoren 2 USB poorten aan de voorzijde, 1 voor een muis, 1 voor een USB opslag apparaat Multi-platform Remote Access Smart Recording; automatisch hoge resolutie opnemen na event trigger Ondersteuning voor externe Disk Array voor meer video opslag capaciteit afmetingen: 345 x 225 x 68,3 mm. DATASHEET
prijzen per stuk excl. BTW


DGH1104
AVTECH 4CHannel NVR POE, H.265, 4K Video Recording, HDMI out
Advanced Video Compression De AVTech DGH1104 NVR heeft H.265 compressie waardoor het opslaan van de camera beelden minder ruimte inneemt en minder bandbreedte vraagt. Uiteraard kunt u ook gewoon H.264 camera's gebruiken. De recorder heeft 4 PoE netwerkaansluitingen voor IP-camera's zodat de stroomvoorziening van de camera's via de netwerkkabel kan.Met de AVTech DGH1104 kunt u de beelden van camera's tot 8 Megapixel opnemen. De beelden kunt u zien door een beeldscherm aan te sluiten op de HDMI aansluiting (tot 4K) . ingebouwde 4 poort switch met PoE voor max. 4 IP-camera's PoE max. 30W per aansluiting, max. 60W totaal max. opname-resolutie: 3264 x 2448 (8MP) max. 120 IPS (images per second), max. 80 Mbps H.265 videocompressie, G711 audiocompressie max. 1 harde schijf tot 10 TB voor het opnemen van beelden(NVR wordt zonder harde schijf geleverd) weergave via beeldscherm : HDMI : max. 3840x2160 beeldpunten VGA : max. 1920x1080 beeldpunten 2x USB aansluitingen Push Status - Actieve gebeurtenis melding Multi-platform Remote Access EagleEyes voor Android en iOS CMS Lite voor Windows Multicast biedt gebruikers in secondaire control rooms beeld zonder vertraging Ondersteuning voor externe Disk Array voor meer video opslag capaciteit Geschikt voor de aansluiting van externe devices om de functionaliteit en de flexibiliteit van uw NVR te vergroten EaZy networking: cloud service om NVR via internet te bekijken afmetingen : 260 x 236 x 48 mm. (bxdxh)DATASHEET
prijzen per stuk excl. BTW


DGH1108
AVTECH 9 CHannel NVR , H.265, 4K Video Recording, HDMI out. Without POE
NVR voor max. 9 IP-camera's (8 camera's via LAN aansluiting met een (PoE) switch + 1 camera's in netwerk via WAN aansluiting) deze NVR heeft geen Power-over-Ethernet (PoE) 1x Gigabit WAN aansluiting naar netwerk/internet 1x Gigabit LAN aansluiting waar een (PoE) switch met de camera's op kan worden aangesloten max. opname-resolutie: 3264 x 2448 (8MP) max. 270 IPS (images per second), max. 120 Mbps H.265 videocompressie, G711 audiocompressie max. 1 harde schijf tot 14 TB voor het opnemen van beelden(NVR wordt zonder harde schijf geleverd) weergave via aan te sluiten beeldscherm : HDMI : max. 3840x2160 beeldpunten (4K) VGA : max. 1920x1080 beeldpunten 2x USB aansluitingen (1 voor muis, 1 voor USB opslag apparaat) Push Status - Actieve melding (HDD defect, verbinding camera weg) door middel van de gratis EagleEyes app Multi-platform Remote Access EagleEyes voor Android en iOS CMS Lite voor Windows Windows webbrowsers : Edge, Chrome, Internet Explorer Multicast biedt gebruikers in secondaire control rooms beeld zonder vertraging Geschikt voor de aansluiting van externe devices om de functionaliteit en de flexibiliteit van uw NVR te vergroten EaZy networking: cloud service om NVR op internet aan te sluiten afmetingen : 260 x 236 x 48 mm. (bxdxh) Datasheet Quick setup
prijzen per stuk excl. BTW


AVH1109AX
AVTECH 8CH NVR POE, HDMI out, H.265, 4K Video Recording Push Video - NDAA compliant
ingebouwde 8 poort switch met PoE voor max. 8 IP-camera's PoE max. 30W per aansluiting, max. 120W totaal max. opname-resolutie: 3264 x 2448 (8MP) max. 270 IPS (images per second), max. 80 Mbps H.265 videocompressie, G711 audiocompressie max. 1 harde schijf tot 16 TB voor het opnemen van beelden(NVR wordt zonder harde schijf geleverd) weergave via beeldscherm : HDMI : max. 3840x2160 beeldpunten VGA : max. 1920x1080 beeldpunten 2x USB aansluitingen (1 voor muis, 1 voor USB opslag apparaat) Push Video & Push Status - Actieve gebeurtenis melding door middel van de gratis EagleEyes app Multi-platform Remote Access EagleEyes voor Android en iOS CMS Lite voor Windows webbrowsers Windows : Edge, Google Chrome, Modzilla Firefox, Internet Explorer, webbrowser MacOS : Google Chrome, Modzilla Firefox Multicast biedt gebruikers in secondaire control rooms beeld zonder vertraging Ondersteuning voor externe Disk Array voor meer video opslag capaciteit Geschikt voor de aansluiting van externe devices om de functionaliteit en de flexibiliteit van uw NVR te vergroten EaZy networking: cloud service om NVR op internet aan te sluiten NDAA compliant afmetingen : 260 x 236 x 48 mm. (bxdxh)DATASHEET Uitleg: voeg snel een NVR toe in EagleEyes app
prijzen per stuk excl. BTW


AVH2117AX
Avtech NVR 16 CH 16CH POE H.265 480 IPS @ 3840 x 2160 160Mbps - NDAA compliant
Wordt eind februari verwacht. De AVTech AVH2117AX is een 16 kanaals videorecorder voor het opnemen van de camera-beelden van maximaal 16 IP-camera's.Op de AVH2117AX recorder zijn 16 PoE aansluitingen voor IP-camera's aanwezig.De maximale opname-resolutie is 8 Megapixel (3840x2160 beeldpunten). De AVH2117AX ondersteunt H.265 videocompressie voor een efficiente opslag van de camera-beelden.In de recorder kunnen maximaal 2 SATA harde schijven tot 16 TB per stuk geplaatst worden. U kunt een HDMI monitor tot 4K aansluiten aan de recorder om de beelden te bekijken of gebruik maken van de EagleEyes app voor Android/iOs of het CMS Lite programma voor Windows.Met de EaZy Networking oplossing kunt u de beelden van de AVTech recorders veilig via internet bekijken.De AVH2117AX recorder voldoen aan de NDAA en TAA richtlijnen. specificaties: Netwerk video-recorder voor max. 16 IP-cameras ingebouwde 16 poort PoE switch voor IP-camera's PoE 802.3af max. 30W per aansluiting, max. 130W totaal max. opname-resolutie: 3860 x 2160 (8MP) max. 480 IPS (images per second), max. 160 MbpsH.265 videocompressie, G711 audiocompressie max. 2 harde schijven tot 16 TB per stuk voor het opnemen van beelden(NVR wordt zonder harde schijf geleverd) weergave op beeldscherm : HDMI : max. 3840x2160 beeldpunten VGA : max. 1920x1080 beeldpunten 2x USB aansluitingen (1 voor muis, 1 voor USB opslag apparaat) audio-in + audio-uit aansluitingen Alarm I/O (4 in, 1 uit) Push Video & Push Status - Actieve gebeurtenis melding door middel van de gratis EagleEyes app op Android of iOS. Multi-platform Remote Access EagleEyes voor Android en iOS CMS Lite voor Windows Webbrowsers: Windows 10 Edge, Chrome, Firefox en Opera, MacOS Chrome en Firefox Multicast biedt gebruikers in secondaire control rooms beeld zonder vertraging Ondersteuning voor externe Disk Array voor meer video opslag capaciteit Geschikt voor de aansluiting van externe devices om de functionaliteit en de flexibiliteit van uw NVR te vergroten EaZy networking: cloud service om NVR op internet aan te sluiten NDAA compliant afmetingen : 319,5 x 254,9 x 52 mm. (bxdxh) Datasheet Quick Installation Guide
prijzen per stuk excl. BTW


NE-2040
NUUO NAS NVR Mini2 incl. 1x 1 Tb HDD
LET OP! 1x Beschikbaar OP=OP nieuw in doos incl. 1x 1 TB HDD Firmware version: 3.0 NAS-based NVR Standalone 4ch, 2bay Streams & Records 4 IP Cameras 4 Camera Events & 4 User Privileges Supports MPEG4/MJPEG/H.264 Formats Panomorph PTZ (360°) Support Up to 128 Cameras On Multiple Monitors 5 Video Analytics Searches RAID 0/1 Support & Dual Streaming E-Mapping / Includes 4 Licenses US Power Cord The NUUO NVRmini2 NE-2040 NVR and Server (4-Channel, 2 Drive Bays, 1TB) is a professional surveillance recording system designed to stream and record live video/audio from 4 IP cameras. The unit also supports dual streaming of MPEG4, MJPEG, and H.264 video compression formats.The NVRmini Recorder and Server features an intelligent playback system with 5 video analytics searches that include general motion, foreign object, missing object, loss of focus, and camera occlusion. With support for RAID 0 and 1, the recorder ensures the highest level of data security at the HDD level. Users can connect to the NVRmini2 via Web Viewer (Internet Explorer) and view up to 16 channels of live video. In addition, the Remote Live Viewer allows viewing of up to 128 channels of live video on multiple monitors from different locations. The streamed footage can be accessed on your iPhone, iPad, Android, Windows Phone 7, and BlackBerry mobile phones via the Internet. All key server functions are available on 1 screen on the GUI menu, making it easy for the users to setup recording schedules (daily or weekly) and configure key server settings. E-mapping, another handy feature in this NVR, offers a quick overview of the surveillance area, indicating the location of the CCTV cameras or the site where an event occurred. The watermark option helps protect the recorded data from being copied or tampered with.Also included in the NVRmini 2 are video enhancement tools for fine-tuning the image visibility, sharpness, brightness, contrast, and grayscale. Video conversion is also possible to AVI or ASF file format. You can also take snapshots from the recordings in BMP or JPEG format to print or save critical images for future use. Note! Supports a maximum of 4 licenses. Surveillance Supports 49 brands of IP cameras, with remote viewing and live video recording Records in MPEG4, M-JPEG, MxPEG, and H.264 formats (depending on the camera model) at a maximum rate of 120 fps Embedded Linux for protection from viruses and system crash Dual streaming for efficient bandwidth management Synchronization of video and audio recording Works with NUUO CMS (Central Management System) for monitoring large scale projects System, Setting, Management and Integration Server-client architecture for routing all video data via NVRmini2 to remote clients to balance the camera load and achieve good recording quality Allows for automatic camera search in the network 1 Set recording schedules daily or weekly via GUI recording scheduler Configure key server functions via the GUI Supports 4 camera events like motion detection (camera should support this), connection lost and camera input; 1 input event from remote I/O box; 3 system events and daily system report via e-mail 3 instant alarms for output, e-mail and NUUO CMS alarm system Built-in RAID 0, 1 to prevent data loss Records live transactions received via NUUO POX box or Ethernet (TCP/IP client) Incorporates POS text overlay on live video and recordings Transactions can be searched in the NVRmini2 database Seamless integration of camera I/O and NUUO I/O box to start recording on input trigger or to trigger output as an event occurs 4 different user groups (admin, power user, user, and guest) for logging into the NAS server via Web Viewer Users can connect to Recording Server via Web Viewer (Internet Explorer) and monitor 16 channels of live video Special privilege for each group in system configuration, live view camera, and playback camera Accurate synchronization of recording time (weekly/monthly) via NTP protocol Easy camera control with joystick support for PTZ cameras For 360° surveillance with support for panomorph lens-based PTZ cameras Allows you to keep a track of system operations via hardware log, camera status, and user access tracking via NVR log, special-event tracking via NVR event log, video export and backup tracking via Export/Backup log Quick start and troubleshooting assistance via user-friendly HELP page Remote Operation Remote Playback application for playback of 16 channels of recording from the NUUO NVRmini2 Remote Live Viewer application for monitoring NVRmini2 at multiple locations simultaneously (PTZ control, E-map and I/O panel) Remote Live Viewer can be used to connect and monitor up to 128 cameras at multiple locations Remote Backup application to backup recording video and POS transaction remotely from NVRmini 2 For access and display of live footage Supports NUUO's mobile client for iPhone, iPad, Android, windows Phone 7, and BlackBerry for remote surveillance Multi-view allows simultaneous viewing of the same video on multiple channels for detailed surveillance E-mapping for complete coverage of the surveillance area, indicating the location of the CCTV cameras Multiple camera streams with lower bitrate can be viewed in real-time without compromising on the quality Playback, Search, Export, and Secure Data Video enhancement tools for fine-tuning the image visibility, sharpness, brightness, contrast, and grayscale Intelligent playback system with 5 video analytics searches: general motion, foreign object, missing object, loss focus, and camera occlusion Convert videos to AVI or ASF file format and take snapshots from recording in BMP or JPEG format for future reference Backup videos in DAT format Alert notification (camera and system event) via sound digital output, e-mail, and NUUO CMS alert Automatic backup of footage of a particular date to the designated FTP server Manual deletion of recorded footage Watermark option for protecting the data from being copied and is also useful for tamper detection
prijzen per stuk excl. BTW


SVR-104 Basic
4CH H. 264 IP recorder voor Soho gebruik (NVR) garantie 1 jaar
4 kanaals IP recorder incl. gratis CMS 16 in 1 Manage up to 4 Network cameras Compatible with Major Brand Cameras support Axis, Sony, Panasonic, AV Tech, Canon, D-Link, ACTI, Zavio, AMTK, Vivotek, Arecont Vision, Etrovision, Level 1, Mobotix, Toshiba, Abus, Planet, Pixord, IQInvision, A-Linking, Brickcom, Hunt, Edimax Max 2 HDD's total max 3 TB (not included) High Quality Live/Playback Video Export Playback Videos to AVI Web-based E-map Event Alert Two-way Audio Smart Camera Search Mobile Devices Remote Monitoring Pure Web Based Administration
prijzen per stuk excl. BTW


WD30PURZ
WD HDD 3TB Purple 64MB 3,5" SATA 6GB/s, 5400 RPM
De slimme keuze voor bewaking Meer camera's, grotere helderheid en betere beveiliging. De Purple WD30PURZ van WD heeft een opslagcapaciteit van 3 TB en een cache van 64 MB. De 3,5 inch SATA harddisk is voorzien van een Serial ATA/600 interface. Deze harde schijf is uitgerust met Allframe en IntelliPower. AllFrame-technologie: Deze technologie zorgt voor een verbeterde opname van de verschillene video streams en verminderd de kans op het verlies van frames en andere stoteringen.Deze harde schijf beschikt over IntelliPower, een verfijnde balans van de rotatiesnelheid, overdrachtssnelheid en caching algoritmen, ontworpen om stroom te besparen en betere prestaties te leveren. Gefabriceerd voor dag en nacht functionerende beveiligingssystemen met hoge resolutie. Met een ondersteunde werkbelasting tot 180 TB per jaar en ondersteuning voor maximaal 64 camera's, zijn WD Purple harde schijven geoptimaliseerd voor beveiligingssystemen. WD Purple harde schijven zijn geoptimaliseerd om tot 64 camera's te ondersteunen, waardoor u de flexibiliteit hebt om een upgrade van uw beveiligingssysteem uit te voeren of dit uit te breiden.
prijzen per stuk excl. BTW


AVX102
USB joystick for AVTECH speed dome camera control on AVTECH DVR, NVR and PC (with CMS Lite installed)
* * Alleen op bestelling * * AVX102 USB Joystick voor AVTECH speed dome camera’s De AVX102 USB-joystick wordt gebruikt in combinatie met AVTECH speed dome camera’s om deze op afstand te kunnen bedienen. Dynamisch of met vooraf vastgestelde instellingen kunnen camera- en lens bewegingen worden aangestuurd. Via NVR, DVR of PC (met CMS Lite geïnstalleerd) kunnen de camera’s eenvoudig en intuïtief op afstand worden bediend. Kenmerken 3 assen voor PTZ (Pan-Tilt-Zoom) besturing 6 indicatoren voor CH/PRESET/SEQUENCE/AUTO PAN/CRUISE/FUNCTIE 25 speciale knoppen/4 programmeerbare knoppen 2 x USB type A connectors (voor muis/USB flash drive/keyboard aansluiting voor gebruik met DVR/NVR) 1 x USB Type B connector (voor stroomvoorziening via PC/DVR/NVR) Voeding via USB-interface (DC 5V/100mA)
prijzen per stuk excl. BTW
Met de AVTech netwerk video recorders (NVR) kunt u de beelden van aangesloten IP-camera's opslaan.
Met duidelijke menu's zijn de recorders simpel in te stellen.
ONVIF compatibiliteit zorgt er voor dat u ook IP-camera's van andere merken kunt aansluiten (mits deze ONVIF compatible zijn)
Alle AVTech NVR hebben EaZy networking. Dit is een oplossing om de beelden van de aangesloten camera's via internet te kunnen bekijken, zonder dat op de modem/router poorten moeten worden open gezet.
De EagleEyes app op Android of iOS geeft toegang tot de beelden van de NVR op mobiele apparaten.
Voorkom hacking
Free P2P Cloud EaZy Networking
EaZy Networking is a free P2P cloud service to connect AVTECH devices to the Internet automatically by plug-and-play, enabling you to check the live view via your mobile device at any time. This service is enclosed in our mobile app, EagleEyes, and you can easily configure your device to the internet on your smart phone / tablet.
This service is free and the transmission speed of your video might be affected by the number of online users who are using this service simultaneously. To obtain stable transmission, it’s recommended to purchase our data plan of 1GB, 7GB, 50GB and 200GB via EagleEyes. Each device will enclose a 2GB data plan for a free trial.
EagleEyes
Push Video
Spot Monitor
In addition to the main display via the HDMI output, you can also assign a secondary display to show live view, call monitor or event monitor via the VGA or composite output.
- Live view: Specify how many channels to display.
- Call monitor: Set the sequence time and display each channel one by one.
- Event monitor: Display only when an event occurs. You can configure how many more seconds you'd like to see before and after the event, helping you to see how the whole event starts and ends.
NDAA
De NDAA richtlijn (National Defense Autohrization Act) van de Amerikaanse overheid houdt in dat er in netwerkcamera's en -recorders geen onderdelen van (bepaalde) Chinese producenten mogen worden gebruikt, om spionage door de Chinese overheid te voorkomen.
In de EU en dus ook Nederland wordt aan overheden dringend geadviseerd geen camera's met Chinese onderdelen te gebruiken.
Er wordt in Europa dus ook naar NDAA compliant producten gevraagd.
Met AVTech kunt u hier een oplossing voor bieden.
AVTech is een Taiwanees bedrijf dat in Taiwan produceert.
Camera's en NVRs van AVTech waarbij "NDAA compliant" staat voldoen aan de NDAA richtlijn en zijn daarmee geschikt om te gebruiken bij overheden en bedrijven.
