Cat.5e Stug (installatie)kabel



Primacom levert alleen kabels met 100% koperen kernen voor de beste signaal overdracht en maximale flexibiliteit.

Installatiekabel wordt gebruikt in de muur/plafond en aangesloten op LSA contacten.

CAT5e 100m

305533
Techly ITP7-UTP-IC-100 Cat5e U-UTP unshielded twisted pair Installatiekabel, 4x2xAWG24/1 koper, PVC, Grijs, 100 meter CE & DOP EN 50575

100m 100% koper De Techly ITP7-UTP-IC-100 Cat5e U/UTP installatie kabel voldoet ruim aan de Cat5e normen en is daardoor geschikt voor gebruik in Class D installaties.De kabel heeft solid bare annealed copper (onthard koper) kernen, voor maximale flexibiliteit en de beste signaaloverdracht. Algemene informatie U/UTP Kabel (unshielded twisted pair – overall unshielded) 4 x 2 x AWG24/1 solid bare annealed copper (onthard koper) Grijze PVC buitenmantel, vlamvertragend, CM riser rating Getest tot 350 MHZ voor extra bandbreedte en performance Standaard getest voor 3P certificerings eisen TIA Cat5e channel getest Ideaal voor 10Base-T, 100Base-TX en 1000BASE-TX Voldoet aan: EIA/TIA-568-B.2; ISO/IEC 11801; EN 50173 CPR/NEN8012 klasse : Eca Markering voor gebruikte kabellengte Lengte: 100 mtr  Primacom levert alleen kabels met bare annealed copper (onthard koper) kernen voor de beste signaal overdracht en maximale flexibiliteit.

€ 29,94
prijzen per stuk excl. BTW
Staffelkorting op dit artikel aanwezig
CAT5e 305m
DK-1511-V-305-1 CAT 5e U-UTP installation cable 305 m

363811
DK-1511-V-305-1 Digitus CAT 5e U-UTP installation cable, 100 MHz Eca (PVC), AWG 24/1, 305 m paper box, sx, grey

305m 100% koper CAT 5e U-UTP installation cable, 100 MHz Eca (PVC), AWG 24/1, 305 m paper box, sx, grey 1GBit Ethernet 100 Mhz transmission frequency PoE Power over Ethernet support CPR class Eca Technical details: Physical properties: Conductor: Bare annealed copper, solid AWG 24/1 Insulation: PE (Polyethylene) Total number of insulated conductors: 8, twisted in 4 pairs Color code: Blue-white, orange-white, green-white, brown-white Individual pair shield: None Overall shielding: None Outer sheath: Eca acc. to EN 50575; PVC Outer sheath diameter (nominal): 0.50 mm nominal Outer sheath color: Grey (RAL 7035) Mechanical properties: Tensile loading: 150N max. Dynamic bending radius: 8x AD mm min. Static bending radius: 4x AD mm min. Shipping- and storage temperature range: -20 °C up to +75 °C Operating temperature range: -20 °C up to +60 °C Installation temperature range: 0 °C up to +50 °C Overall diameter Simplex (nominal): 4.7 mm nominal Electrical properties: Impedance: 100±5 Ohm @ 1-600 MHz Capacitance: 40 pF/m nominal @ 800 Hz Capacitance unbalance (pair-ground): 1.5 pF/m max. @ 1 KHz Insulation resistance: 5 GOhm x km min. DC loop resistance: 147 Ohm/km max. (2% max. resistance unbalance) Voltage resistance: 72 Vdc max. Coupling attenuation: CA-Type 3 Signal propagation delay: 535 nS/100 m max. Propagation delay: 20 nS/100 m max. Separating class: ,,b" acc. to EN 50174-2 NVP: 69% AWG-size: 24 Category: 5E Colour outer sheath: Grey Conductor category: Class 1 = solid Conductor material: Cu, bare Core identification: Colour Core insulation: PE (polyethylene) Flame retardant: No Halogen free (acc. EN 60754-1/2): no Low smoke (acc. EN 61034-2): no Material outer sheath: PVC Number of cores: 8 NVP value: 69 Outer diameter approx.: 5 Permitted cable outer temperature, fixed (MIN): -20 … 60 Permitted cable outer temperature, in movement (MIN): -20 … 75 Screen over stranding: None Screen over stranding element: None Stranding element: Pairs

€ 124,38
prijzen per stuk excl. BTW
Staffelkorting op dit artikel aanwezig
