Cat.8.1 Field Termination Plug, shielded, Tool free, Black
25/40GBase-Transmission speed in permanent Link up to 24 m and Channel Link up to 30 m. Especially for ToR and MoR cabling in the data center.
The Cat. 8.1 plug for field assembly achieves transmission speeds of 25GBase-T or 40GBase-T - in permanent link up to 24 m and in channel link up to 30 m
With the tool-free bracket connection for solid and stranded conductors with AWG 26/7 to 22/1 in accordance with EIA/TIA 568 A&B, robust Ethernet patch cables can be assembled for field applications
Field termination RJ45 plugs are suitable, for example, for temporary fitting on installation cables for repair or maintenance, or as a long-term connection between two installation cables.
The ISO/IEC 11801 & IEC 60603-7-81 compliant category 8 network plug is suitable for ToR and MoR cabling in data centers, and is downwardly compatible with Cat 6A, Cat 6, Cat 5e, …
The cable grip and screw cap cable fixation as well as the metal housing made of nickel-plated die-cast zinc ensure 360 ° shielding of the Cat. 8.1 plug.
The article "DN-93837" of the brand DIGITUS® is a shielded CAT 8.1 field connector with tool-free mounting connection, which convinces by future-oriented standards and high-end quality for your network. The field connector is suitable for patch cable mounting with solid and stranded conductor cables. It conforms to category 8.I / 25/40GBase-T ISO/IEC 11801, IEC 60603-7-81. The robust metal housing ensures durable, stable connections. The quick assembly without special tools makes this field connector the optimal choice for installation, repair and maintenance.
Technical details:
Transmission properties:
Category 8.I - 25/40 GBase-T, 2000 MHz
ISO/IEC 11801 3rd Edition, EN 50173-1
Suitable for PoE/PoE+/4PPoE (IEEE 802.3af, 3at, 3bt)
General properties:
Suitable for patch chord assembly
RJ45 female, 8P8C
Tool-free cable installation via IDC strips, color coded according to EIA/TIA 568 A & B
Cable fixation by screwable strain relief
Tool-free mounting connection
360° shield coverage
Technical properties:
Housing material: Zinc die-cast, nickel-plated
Contact material: Phosphor bronze
Coating of the contacts: Nickel, gold-plated 0.5 µ
Physical properties:
Insertion force: 30N max. (IEC 60603-7-5)
Retention strength: 7.7 kg between jack and plug
Operation temperature: -20° C to +70 °C-20°C bis zu +70°C (ISO/IEC 11801, ANSI/TIA 568 C.2)
Mating cycles female: > 750 (ISO/IEC 11801, IEC 60603-7-81)
IDC wire size: AWG (26/7 - 22/1), solid and stranded conductor
Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
Compatible with keystone module DN-93815 and installation cable DK-184X-VH
Measurements: (HxBxT): 19,5 x 15,0 x 58,3 mm
Weight: 38.0 g
€ 7,43
prijzen per stuk excl. BTW
