10 inch patchpanels

Cat5e
DIGITUS CAT 5e, Class D Patch Panel, shielded, black

241485
DN-91508S 10" Shielded patch panel, CAT5E. 8-port

DIGITUS CAT 5e, Class D Patch Panel, shielded, 8-port RJ45, 8P8C, LSA, 1U, 254mm(10")Rack Mount Color black RAL 9005 Transmission properties: Category 5e Area of application: Up to 100 MHz, 10/100Base-T, 1GBase-T Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C General properties: Suitable for 254 mm (10") cabinet mounting RJ45 female, 8P8C Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B Cable fixing with smart cable ties Central ground connection 360° shield coverage Mechanical properties: Housing material: 1.5 mm galvanic cold rolled steel, acc. to EN1.4301, UNS S30400, AISI 304 and LMSAD110 RJ45 female material: ABS UL 94V-0 RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact RJ45 shielding: Tinned bronze LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze Ground wire: Not included Conductor plate: FR4, UL 94V-0 Physical properties: Insertion force: 30N max. (IEC 60603-7-5) Retention strength: 7.7 kg between jack and plug Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C) Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5 Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5 IDC wire size: 22 – 26 AWG solid and stranded conductor Insulation resistance: > 500 MOhm Contact resistance: < 20 MilliOhm Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground) Color: Black (RAL 9005) Category: 5E Colour: Black Connection type: LSA Depth: 109 Height: 44 Mounting method: 254 mm (10 inch) mounting Number of buses/couplings: 8 Number of height units: 1 RAL-number: 9005 Screened: yes Suitable for number of connectors: 8 Type of connector: RJ45 8(8) Width: 482

€ 21,19
prijzen per stuk excl. BTW
Staffelkorting op dit artikel aanwezig
Cat6
DIGITUS CAT 6, Class E Patch Panel, shielded, black

241577
DN-91608S 10" Shielded patch panel, CAT6, 8 -port

DIGITUS CAT 6, Class E Patch Panel, shielded, 8-port RJ45, 8P8C, LSA, 1U, 254mm(10")Rack Mount Color black RAL 9005 Easy wire installation possible due to color coded LSA strips Shielding provides optimized performances Compact 10" design with 8x RJ45 ports Technical details: Transmission properties: Category 6 Area of application: Up to 250 MHz, 1GBase-T Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C General properties: Suitable for 254 mm (10") cabinet mounting RJ45 female, 8P8C Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B Cable fixing with smart cable ties Integrated dust cover Central ground connection 360° shield coverage Mechanical properties: Housing material: 1.5 mm galvanic cold rolled steel, acc. to EN1.4301, UNS S30400, AISI 304 and LMSAD110 RJ45 female material: ABS UL 94V-0 RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact RJ45 shielding: Tinned bronze LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze Ground wire: Not included Conductor plate: FR4, UL 94V-0 Physical properties: Insertion force: 30N max. (IEC 60603-7-5) Retention strength: 7.7 kg between jack and plug Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C) Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5 Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5 IDC wire size: 22 – 26 AWG solid and stranded conductor Insulation resistance: > 500 MOhm Contact resistance: < 20 MilliOhm Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground) Color: Black (RAL 9005) Color: black, RAL 9005 Ports: 8 Units: 1 Category: CAT 6

€ 24,38
prijzen per stuk excl. BTW
Staffelkorting op dit artikel aanwezig
Cat6
DN-91612S 10 Shielded patch panel, CAT6, 12-port

241591
DN-91612S 10" Shielded patch panel, CAT6, 12-port

CAT 6, klasse E patchpaneel, afgeschermd, 12-poorts RJ45 8P8C, LSA, 1HE, 254mm(10")rack mount, Zwart RAL 9005 De CAT 6 patchpanel voor 10" rekmontage van DIGITUS® worden vervaardigd volgens Link Performance klasse E, tot max. 250 MHz, ISO/IEC 11801 en EN 50173. Kabelinstallatie geschiedt via LSA-klemmen, met kleurcodering volgens EIA/TIA 568B. De behuizing bestaat uit gegalvaniseerd koudgewalst staal volgens EN1.4301, UNS S30400, AISI 304 en LMSAD110. Eenvoudige kabelinstallatie mogelijk door kleurgecodeerde LSA-strips Afscherming zorgt voor optimale meetwaarden Compact 10”ontwerp met 8x RJ45 connector Technische details: Transmissie eigenschap Categorie 6 Toepassingsgebieden: Maximaal 250 MHz, 1GBase-T Normen: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C Algemene eigenschappen: Geschikt voor 254 mm (10") kastmontage RJ45-connector, 8P8C Kabelinstallatie via LSA strips, kleurgecodeerd volgens EIA/TIA 568 A & B Kabelbevestiging door middel van kabelbinders Centrale aardaansluiting 360°-schild contact Mechanische eigenschappen: Materiaal behuizing: 1,5 mm verzinkt koudgewalst staal volgens EN1.4301, UNS S30400, AISI 304 en LMSAD110 Materiaal RJ45 connector: ABS UL 94V-0 Contact RJ45 connector: Vernikkeld fosforbrons 0,5 μ verguld contact RJ-45-afscherming: Vernikkeld brons LSA-snijklem: Krone LSA+, UL 94V-2, verzinkt fosforbrons Aarddraad: Niet inbegrepen bij de levering Printplaat FR4, UL 94V-0 Fysische eigenschappen: Insteekkracht: 30N max. (IEC 60603-7-5) Trekbelasting: 7,7 kg tussen connector en stekker Bedrijfstemperatuur: -20° C tot +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C) Insteekcycli connector: > 750 volgens ISO/IEC 11801, IEC 60603-7-5 Klem: > 200 volgens ISO/IEC 11801, IEC 60603-7-5 Aderbezetting: 22-26 AWG massief en litzedraad Isolatieweerstand: > 500 MOhm Contactweerstand: < 20 MilliOhm Doorslagvastheid: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Massa) Kleur: Zwart (RAL 9005) Eenheden: 1 Kleur: zwart, RAL 9005 Poorten: 12 Categorie: CAT 6 QIG

€ 33,69
prijzen per stuk excl. BTW
Staffelkorting op dit artikel aanwezig
